圆锥滚子轴承

双列圆锥滚子轴承，轴承有一个外圈和两个内圈，两个内圈之间有垫片。可以通过改变间隔件的厚度来调节间隙。它可以同时承受径向载荷和双向轴向载荷。双列圆锥滚子轴承通常用于齿轮箱、起重设备、轧机和采矿业中的机器，例如隧道掘进机。

类别:

圆锥滚子轴承

关键词:

圆锥滚子轴承

产品描述

产品详细信息

轴承编号	尺寸 (mm)
352224D	120 × 215 × 312
350620D1	100 × 190 × 125
350626D1	130 × 235 × 145
350630D1	150 × 255 × 145
352132X2D1	160 × 270 × 140
352936X2D1/YA1	180 × 250 × 95
350636D1	180 × 285 × 108
350641D1	205 × 320 × 150
3506/203.2D1/YA3	203.2 × 276.225 × 95.25
350645D1	225 × 360 × 146.5
350646D1	230 × 360 × 146.5
350652D1	260 × 430 × 180
3506/254D1	254 × 431.724 × 180
350660D1	300 × 440 × 140
352052X2D1	260 × 400 × 150
350668D1	340 × 500 × 155
350672D1	360 × 530 × 155
351084X2D1	420 × 620 × 190
350680D1	400 × 590 × 185
352930X2D	150 × 210 × 80
352034X2D	170 × 260 × 120
350307X2D	35 × 80 × 57
372218	90 × 160 × 94
372011X2	55 × 90 × 54
372016X2	80 × 125 × 58
372222X3	110 × 210 × 118
372224X2	120 × 215 × 87
371180X2	400 × 650 × 200
371180X2/HCYA	400 × 650 × 240
371184X2	420 × 700 × 224
371188X2	440 × 720 × 226
3711/500X2	500 × 830 × 330
178880SU	400 × 650 × 240
370622	110 × 240 × 118
3706/260.35	260.35 × 444.5 × 196.85
3706/228.925	228.925 × 406.4 × 114.463
3706/550B/HCC2	550 × 920 × 330
K87718-1Y	88.9 × 279.4 × 101.6
3706/305 07	305.07 × 500 × 200
370660/YA	300 × 440 × 105
3706/500	500 × 730 × 280
3706/501.625	501.625 × 711.2 × 250.825
3706/501.625/P6	501.625 × 711.2 × 250.825
3706/501 13/HC	510.3 × 800 × 285
3506/520	520 × 740 × 190
3506/530	530 × 730 × 250
3706/670B/YA	670 × 980 × 230
3706/570	570 × 750 × 280
351976	380 × 520 × 145
351980	400 × 540 × 150
31980/P59	400 × 540 × 150
351984	420 × 560 × 145
351984/P59	420 × 560 × 145
351988	440 × 600 × 170
351992	460 × 620 × 170
351996	480 × 650 × 180
3519/500	500 × 670 × 180
3519/500/HC	500 × 670 × 180
3519/530	530 × 710 × 190
3519/530J	530 × 710 × 190
3519/560	560 × 750 × 213
3519/600	600 × 800 × 205
3519/600HC	600 × 800 × 205
3519/630	630 × 850 × 242
3519/630/C2	630 × 850 × 242
3519/670	670 × 900 × 240
3519/710	710 × 950 × 240
3519/750	750 × 1000 × 264
3519/750HC	750 × 1000 × 264
3519/800/S0	800 × 1060 × 270
3519/800/C3S0	800 × 1060 × 270
3519/800	800 × 1060 × 270
3519/850	850 × 1120 × 268
3519/900	900 × 1180 × 275
3519/950/HC	950 × 1250 × 300
3519/950	950 × 1250 × 300
3519/1120	1120 × 1460 × 335
352926	130 × 180 × 70
352928	140 × 190 × 73
352930	150 × 210 × 80
352932	160 × 220 × 82
352934	170 × 230 × 82
352936	180 × 250 × 90
352938	190 × 260 × 95
352940	200 × 280 × 105
352944	220 × 300 × 110
352948	240 × 320 × 110
352952	260 × 360 × 134
352956	280 × 380 × 134
352960	300 × 460 × 160
352964	320 × 460 × 160
352968	360 × 460 × 160
352972	360 × 480 × 160
351056	280 × 420 × 133
351068	340 × 520 × 180
351072	360 × 540 × 185
351072/YA1	360 × 540 × 185
351076	380 × 560 × 190
351080	400 × 600 × 206
351088	440 × 650 × 212
351092	460 × 680 × 230
351096	480 × 700 × 240
3510/500	500 × 720 × 236
3510/500J	500 × 720 × 236
3510/530	530 × 780 × 255
3510/560	560 × 820 × 260
3510/600	600 × 870 × 270
3510/630	630 × 920 × 295
3510/670	670 × 980 × 310
3510/710	710 × 1030 × 315
352015	75 × 115 × 58
352026	130 × 200 × 102
352028	140 × 210 × 95
352030	150 × 225 × 110
352032	160 × 240 × 116
352032/YA	160 × 240 × 116
352034	170 × 260 × 128
352034/YA	170 × 260 × 128
352036	180 × 280 × 142
352038	190 × 290 × 142
352040	200 × 310 × 154
352044	220 × 340 × 166
352060	300 × 466 × 210
351160	300 × 500 × 205
351176	380 × 620 × 242
351184HC	420 × 700 × 275
352122	110 × 180 × 95
352124	120 × 200 × 110
352126	130 × 210 × 110
352128	140 × 225 × 115
352130	150 × 250 × 138
352132/YA1	160 × 270 × 150
352132/YB	160 × 270 × 150
352134/W33	170 × 280 × 150
352134	170 × 280 × 150
352136	180 × 300 × 160
352140	200 × 340 × 184
352140/YA1	200 × 340 × 184
352148	240 × 400 × 210
352152	260 × 440 × 225
352208	40 × 80 × 55
352210	50 × 90 × 55
352212	60 × 110 × 66
352211	55 × 100 × 60
352214	70 × 125 × 74
352215	75 × 130 × 74
352216	80 × 140 × 78
352217	85 × 150 × 86
352218	90 × 160 × 94
352219	95 × 170 × 100
352220	100 × 180 × 107
352221	105 × 190 × 115
352222	110 × 200 × 121
352224	120 × 215 × 132
352224/YA	120 × 215 × 132
352228	140 × 250 × 153
352230	150 × 270 × 164
352232	160 × 290 × 178
352234	170 × 310 × 192
352236/S0	180 × 320 × 192
352236	180 × 320 × 192
352238	190 × 340 × 204
352240	200 × 360 × 218
351980X2	400 × 540 × 70
352926X2	130 × 180 × 70
3529X2	160 × 220 × 82
352934X2	170 × 230 × 82
352936X2	180 × 250 × 95
352936X2/YA1	180 × 250 × 95
352938X2	190 × 260 × 95
352940X2	200 × 280 × 110
352940X2/YA1	200 × 280 × 116
352944X2	220 × 300 × 110
352948X2/YB2	240 × 320 × 105
352948X2/YA1	240 × 320 × 110
352948X2	240 × 320 × 110
352948X2/YA	240 × 320 × 110
352952X2/YB2	260 × 360 × 108
352952X2/YAYB2	260 × 360 × 108
352952X2	260 × 360 × 134
352952X2/YA1	260 × 360 × 134
352952X2-2	260 × 360 × 105
352956X2	280 × 380 × 134
352956X2/P59	280 × 380 × 134
352960X2/P59	300 × 420 × 160
352960X2	300 × 420 × 175
352960X2-2	300 × 420 × 175
352964X2	320 × 440 × 160
352964X2/C2	320 × 440 × 160
352968X2	340 × 460 × 160
352972X2	360 × 480 × 160
3529/1600X2	1600 × 2060 × 560
351080X2	400 × 600 × 230
351072X2	360 × 540 × 169
351076X2	380 × 560 × 171
3510/710 x2/C3	710 × 1030 × 236
3510/710X2	710 × 1030 × 236
352026X2	130 × 200 × 95
352028X2/YA	140 × 210 × 75
352028X2	140 × 210 × 95
352032X2	160 × 240 × 115
352034X2	170 × 260 × 120
352036X2	180 × 280 × 134
352014X2	70 × 110 × 98
352040X2/YA	200 × 310 × 152
352040X2	200 × 310 × 152
352044X2/YA	220 × 340 × 165
352044X2	220 × 340 × 165
352048X2	240 × 360 × 165
352048X2/YA	240 × 360 × 165
352052X2/YA	260 × 400 × 186
352052X2	260 × 400 × 186
352056X2/YA	280 × 420 × 186
352056X2	280 × 420 × 186
352060X2	300 × 460 × 210
352060X2/C4	300 × 460 × 210
352064X2	320 × 480 × 151
352064X2/YA	320 × 480 × 151
352064X2/C9	320 × 480 × 151
352064X2F1	320 × 480 × 151
352064X2/C3	320 × 480 × 151
352072X2/YA	360 × 540 × 220
352072X2	360 × 540 × 220
352080X2	400 × 600 × 230
351160X2	300 × 500 × 200
371180X2B/HCC9	400 × 650 × 200
3511/500X2	500 × 830 × 330
352122X2/YA	110 × 180 × 76
352130X2	150 × 250 × 109
35213X2/C3S0	150 × 250 × 109
351232X2	160 × 270 × 150
352132X2/公顷	160 × 270 × 150
352134X2/YA	170 × 280 × 150
350210X2	50 × 90 × 49
350222X2	110 × 200 × 92
352214X2	70 × 125 × 75
372216X2	80 × 140 × 56.75
372216X2/P6	80 × 140 × 56.75
352216X2	80 × 140 × 80
352217X2/YA	85 × 150 × 84
352218X2	90 × 160 × 95
352220X2-2	100 × 180 × 67.3
352220X2	100 × 180 × 112
352221X2	105 × 190 × 117
352222X2/YA1	110 × 200 × 92
352222X2	110 × 200 × 74
352226X2	130 × 230 × 149
352228X2	140 × 250 × 157
352230X2/YA	150 × 270 × 169
352230X2	150 × 270 × 172
352232X2	160 × 290 × 180
352236X2	180 × 320 × 190
350602	15 × 38 × 46
352013	65 × 100 × 60
350614	68 × 115 × 79.7
350615	74 × 132 × 71
3506/99.5	99.5 × 182 × 160
3506/99 5/S0	99.5 × 182 × 160
350620	100 × 182 × 112
350626/C9	130 × 214 × 115.6
3506/129.5	129.5 × 230 × 208
350633/C9	165 × 290 × 150
350636	180 × 340 × 180
350636/C3	180 × 340 × 180
350652	260 × 430 × 180
350660	300 × 420 × 175
3706/305 079/YA	305.079 × 500 × 200
3709/305 079	305.079 × 500 × 200
350666	330 × 420 × 100
350670	350 × 590 × 200
350672	360 × 530 × 155
3509/382/公顷	381 × 590.55 × 244.475
350688	440 × 650 × 196
350698	490 × 640 × 180
3506/710/C3	710 × 1030 × 236
3506/720	720 × 915 × 190
879/839 8	839.8 × 1333.5 × 463.55
3506/1600	1600 × 2060 × 560
352220X2-2Z	100 × 182 × 117
352226X2-2Z-2	129 × 230 × 222
352223X2-2Z-1	129.5 × 230 × 222
352226X2-2Z	130 × 230 × 222
197726Y	130 × 230 × 222
197726-1	130 × 230 × 222
197726-2	130 × 230 × 222
197726K1	130 × 230 × 222
197726K2	130 × 230 × 222
352226X3-2Z/HG	130 × 250 × 160
352223X3-2Z/HGS0	130 × 250 × 160
3522262Z/S0	130 × 230 × 150
352226X1-2Z	130 × 250 × 217
352230-2Z	150 × 270 × 170
350626-2Z/YB2	129.5 × 230 × 222
3506/144 463-2Z	144.463 × 220.79 × 163.373
3506/119.095	119.095 × 195.26 × 136.5
3506/165 087	119.087 × 301.701 × 190.5
